Victron BatteryProtect BP-65 - 65AMP - 6-35 VDC

p strong BatteryProtect BP-65 - 65AMP - 6-35 VDC strong p p strong Features strong p ul li The BatteryProtect disconnects the battery from non essential loads before it is completely discharged which would damage the battery or before it has insufficient power left to crank the engine nbsp li li 12 24V auto ranging The BatteryProtect automatically detects system voltage nbsp li li Programming made easy The BatteryProtect can be set to engage disengage at several different voltages The seven segment display will indicate which setting has been chosen nbsp li li A special setting for Li-ion batteries In this mode the BatteryProtect can be controlled by the VE Bus BMS Note the BatteryProtect can also be used as a charge interrupter in between a battery charger and a Li-ion battery See connection diagram in the manual nbsp li li Ultra low current consumption This is important in case of Li-ion batteries especially after low voltage shutdown Please see our Li-ion battery datasheet and the VE Bus BMS manual for more information nbsp li li Over voltage protection To prevent damage to sensitive loads due to over voltage the load is disconnected whenever the DC voltage exceeds 16V respectively 32V li li Ignition proof No relays but MOSFET switches and therefore no sparks li li Delayed alarm output The alarm output is activated if the battery voltage drops below the preset disconnect level during more than 12 seconds Starting the engine will therefore not activate the alarm The alarm output is a short circuit proof open collector output to the negative minus rail max current 50 mA The alarm output is typically used to activate a buzzer LED or relay Delayed load disconnect and delayed reconnect The load will be disconnected 90 seconds after the alarm has been activated If the battery voltage increases again to the connect threshold within this time period after the engine has been started for example the load will not be disconnected The load will be reconnected 30 seconds after the battery voltage has increased to more than the preset reconnect voltage li ul p Warranty Info p p strong WARNING strong This product can expose you to chemicals which are known to the State of California to cause cancer birth defects or other reproductive harm For more information go to P65Warnings ca gov p strong Please contact your dealer for any returns repairs or support issues related to this product strong --- cis2 m2hrm5Rq ---
