Blue Sea 7622100 ML ACR Charging Relay 12V 500A w/Manual Control & Deutsch Connector

p strong 7622100 ML ACR Charging Relay 12V 500A with Manual Control amp Deutsch Connector strong p p 500 Amp magnetic latching bi-stable relay automatically combines batteries during charging and isolates batteries when discharging and when starting engine p p strong Features strong p ul li Manual control switch provides an added level of safety allowing control with or without power and offering LOCK OFF capability for servicing li li Automatically manages the charging of two large battery banks li li Allows paralleling of battery banks for emergency starting li li 500 Ampere continuous rating to support high-output alternators li li Magnetic Latch ML mdash ACR draws very low current 40mA to monitor terminal voltage in the ON or OFF states and draws moderate current for very short time when changing state li li Dual sensing mdash senses charge on both battery banks li li Start Isolation SI mdash can be configured for temporary isolation of House loads from Engine circuit during engine cranking to protect sensitive electronics li li Engine Isolation EI mdash can be configured for isolation of two engines while both are running to protect engine electronics and maximize alternator output li li Senses charging on two battery banks li li LED output to remotely indicate when batteries are combined isolated in voltage lockout or in Start or Engine isolation li li 3 8 -16 tin-plated copper studs for maximum conductivity and corrosion resistance li li 7 8 22mm stud length accepts multiple cable terminals li li Silver alloy contacts provide high reliability for switching live loads li li Label recesses for circuit identification li ul p strong Specifications strong p ul li Control Circuit Connection Deutsch DTM li li Nominal Voltage 12VDC li li Manual Control Yes li li Engine Isolation Yes li li Mounting 10 li li Start Assist Yes li li Start Isolation Yes li li Amperage Operating Current 13mA li li Amperage Operating Current When Changing State 7 0A li li Terminal Stud Torque 140 in-lb 15 82 Nm li li Continuous Rating 500A li li Intermittent Rating 700A 5 min li li Cranking Rating 30 Seconds 1450A DC li li Cable Size to Meet Ratings 2x 4 0 li li Live Current Switching 300A 12VDC li li Switching Cycles 100 000 li li Terminal Ring Diameter Clearance 1 18 29 97 mm li li Terminal Stud Length 0 875 22 23 mm li li Terminal Stud Size 3 8 - 16 M10 li ul p strong WARNING strong This product can expose you to chemicals including di 2-ethylhexyl phthalate dehp which is known to the State of California to cause cancer birth defects or other reproductive harm For more information go to P65Warnings ca gov p --- cis2 m2hrm5Rq ---
